Fully Automatic Paper Bag Making Machine with Twisted Rope Handle Paper Bag Making Machine
Overview Product Description Paper bag machine series is applied to produce many types of paper bags without handles, su
Overview
Basic Info.
| Model NO. | RKFD-330 |
| Speed | High |
| Width | 130-330mm |
| Size and Shape | L8600*W3700*H1800mm |
| Long | 260-530mm |
| Weight | 8500 Kgs |
| Material | Paper |
| Usage | Shopping Bag, Garment Bag, Leisure Food Bag, Bread Bags, Airsickness Bag, Fruit Bag |
| Paper Roller Width | 430-1050mm |
| Paper Roller Inner Diameter | 76mm |
| Max. Paper Roller Diameter | 1200mm |
| Paper Bag Width | 130-330mm |
| Paper Bag Bottom Width | 70-180mm |
| Paper Bag Cutting Length (C) | 260-530mm |
| Transport Package | Wooden Package |
| Specification | customized |
| Trademark | ROKIN |
| Origin | Wenzhou, Zhejiang |
| HS Code | 8441200000 |
| Production Capacity | 200 Sets |
Product Description
Product Description
Paper bag machine series is applied to produce many types of paper bags without handles, such as food paper bag, shopping bags and so on.
Samples
| Model | RKFD-190 | RKFD-330 | RKFD-450 | RKFD-450B | RKFD-550 |
| Paper bag cutting length (C) | 190-370mm | 260-530mm | 260-530mm | 360-800mm | 360-800mm |
| Paper bag width (W) | 80-190mm | 130-330mm | 150-450mm | 220-450mm | 220-550mm |
| Paper bag bottom width (H) | 50-100mm | 70-180mm | 70-180mm | 100-250mm | 100-250mm |
| Paper thickness | 45-120g/m2 | 60-160g/m2 | 60-150g/m2 | 80-160g/m2 | 80-160g/m2 |
| Max. Paper bag speed | 150-200pcs/min | 150-200pcs/min | 150-200pcs/min | 150-200pcs/min | 150-200pcs/min |
| Paper roll width | 290-610mm | 430-1050mm | 570-1290mm | 670-1430mm | 670-1630mm |
| Air supply | 0.6-1.2Mpa | 0.6-1.2Mpa | 0.6-1.2Mpa | 0.6-1.2Mpa | 0.6-1.2Mpa |
| Air consumption | 0.12m3/min | 0.12m3/min | 0.12m3/min | 0.12m3/min | 0.12m3/min |
| Power | 11 KW | 8 KW | 8 KW | 15 KW | 15 KW |
| Weight | 5000 KGS | 8500 KGS | 10000 KGS | 12000 KGS | 14000 KGS |
| Dimension | L8*W3*H2m | L9.2*W2.1*H2m | L9.2*W2.45*H2m | L11*W3.4*H2m | L11*W3.4*H2m |
Detailed Photos
Company Profile
Wenzhou Rokin Machinery CO. Ltd is the manufacturer of full automatic paper bag machine, square bottom paper bag machine, v bottom paper bag machine, case making machine, cardboard slitting machine and related auxiliary equipment, etc.
